Advanced Workshop Tools Desktop 1

Overview

Starting at $2,190, the Advanced Workshop Tools Desktop 1 CNC Machine is a powerful evolution of the original Bluey — built for creators who demand precision, strength, and flexibility.
Available in three customizable sizes, the Bluey V2 is capable of cutting soft and hardwood timbers, plastics, and light-duty soft metals such as aluminum.

This model introduces significant upgrades across structure, motion, and control systems:

• +50% rigidity from reinforced 6mm steel plates

• 2–4x thicker gantry for increased stability

• +30% torque from closed-loop integrated stepper motors

Together, these improvements close the performance gap between the Desktop 1 and the higher-end Turbo, delivering premium precision at a more accessible price.

Key Specifications

Base Model: 1×1 meter CNC (1000mm rail, 750×750mm cutting area, 100mm height clearance)
Controller: Arduino Uno CNC Controller running Grbl 1.1h (preloaded with optimized settings)
Motors: NEMA 23 integrated closed-loop stepper motors (340 oz-in, 8mm shaft)
Power Supply: Australian-approved 24V — runs efficiently on just 40 watts
Motion System: GT3 reinforced belts with 20-tooth pulleys
End Mills: Includes $50 worth of bits from Endmill.com.au
Limit Switches: X, Y, and Z proximity sensors return to zero (0,0,0) automatically
Frame Construction: 6mm steel plates, powder-coated in BlueCarve Blue
Cabling: 8-core shielded robot-flex cable for durability and signal reliability

Size Options

The only upgrade you cannot add later is machine size — so choose the version that best fits your workspace and project needs.

Motion & Structure Upgrades

• Reinforced steel gantry and precision-milled plates enhance rigidity and long-term accuracy.

• Closed-loop integrated stepper motors deliver smoother performance and automatic position correction.

• Built-in Z-axis linear block upgrade (previously a $150 add-on) now comes standard.

• Includes a 65mm mount ready for your Makita trimmer or 1.5kW spindle.

Power & Performance Add-Ons

1.5kW Air-Cooled Spindle (+$700)

The Bluey V2 ships ready for a Makita RT0700CX trimmer, which offers plug-and-play simplicity without needing a VFD or cooling system.
For higher accuracy and power, upgrade to a 1.5kW air-cooled spindle, offering:

• Up to 2x power output

• Runout accuracy of 0.008mm (vs. 0.1mm+ on trimmers)

• Maintenance-free air cooling (minimum 7,200 RPM)

Laser Module

Convert your CNC into a hybrid engraving and cutting system with the BluLaser upgrade.
Each kit includes everything you need to get started (software sold separately, approx. $84 USD).

• 7.5W Laser: Ideal for engraving timber and cutting thin ply (~2mm)

• 10W Laser: Cuts up to 5mm ply with air assist and deeper engravings

Z-Probe (+$30)

Save time and improve cut accuracy with a 15mm aluminum puck Z-Probe that automatically sets material height before carving.

T-Slot Rails & Clamps

Add aluminum T-slot rails mounted to an 18mm MDF baseboard for fast, repeatable workpiece clamping.
Includes optional T-slot clamps for a complete hold-down system.
(MDF wasteboard not included — user to supply.)

Surfacing Bit & Collet Options

For perfect leveling, add a surfacing bit and Makita 6mm collet (+$30).
Optional collets also available:

• 3.175mm (+$20)

• 4mm (+$20)

• 6mm (+$20)

• 8mm (+$20)

A 3.175mm-to-6.35mm reducer is included with all Makita packages (normally $28.95).

Dust Boot (+$55)

Add a basic dust boot designed for both the Makita trimmer and 1.5kW spindle to maintain clean, efficient operation and protect moving components.

Why Choose the Bluey V2 from Advanced Workshop Tools

• Veteran-owned company built on precision, reliability, and integrity

• Engineered for makers, woodworkers, and small businesses who demand industrial results

• Modular design allows easy upgrades and maintenance

• Runs efficiently on low power, ideal for garage and workshop environments

• Backed by U.S.-based support and service
